Converter manual

• Insert converter to the programmer ZIF socket according to the picture placed near of it. Insert the device into the converter ZIF socket. The right position of the programmed device in converter ZIF socket is shown at picture near (mainly left above) the converter ZIF socket. Push the device carefully into it. During insertion of device into converter ZIF socket it must be continously parallel to the PCB of the converter.
• Visually check interconnection between device and converter ZIF socket. If everything looks OK, the device is ready for programming.
• Be careful, because the incorrect insertion of converter to the programmer ZIF socket or device to the converter ZIF socket can damage the programmed device. Also incorrect insertion of device to the converter ZIF socket can damage its contacts.
• To take out the device, push the converter ZIF socket. Be careful, because the device can "jump out" from the converter ZIF socket.
• When you finish work with converter, remove it from the programmer ZIF socket.
• Do not directly touch the pins of the converter and converter ZIF socket, because dirt may cause errors during programming of device.
• For handling with the device we recommended to use a vacuum pick up tool.

Accepted package(s)
