Converter
LGA-Bottom-188
- bottom board of BGA
converters, assigned for Intel PF38F5060M0Y3DF and
PF38F5060M0Y3DF
-
socket: 8+3 rows,
sockets for 8x25+3x20 wire wrap pin
- bottom:
2 rows, 2x 24 pins, square,
0.6x0.6mm, rows spacing 600mil
- order no.: 70-1119
- Price: €
|
|
|
Converter manual
- For work with LGA device it is
necessary put together LGA-Bottom-188 with some LGA-Top-x ZIF-CS board according the information
provided by PG4UW software.
- Do not directly touch the pins of
the converter, because dirt may cause errors during
programming of device
- The picture show, how to put
together the LGA-Top-x ZIF-CS and LGA-Bottom-x boards
to have complete LGA converter.
 |
|
|
|
